ANALECT Diamond MX

Benchtop FTIR Analyzer for Liquids,
Solids & Gas Compositions

Flexibility Built-In: Convenient Rackmount or Benchtop Option

Our ANALECT® Diamond MX™ FT-NIR process analyzer is configured for both rackmount or benchtop applications. It provides rapid, accurate and stable real-time monitoring of physical properties and chemical composition of liquids, solids and gases, with just one instrument.  Its rackmount chassis fits all standard 19″ racks and comes with nine different sampling devices can be used with the same ANALECT Diamond MX analyzer including transmission and gas cells, diffuse reflectance heads, fiber-optic flow-through cells and NIR immersion probes.

It provides rapid, accurate and stable real-time monitoring of physical properties and chemical composition of liquids, solids and gases.  The entire beam is switched from channel to channel, enhancing energy throughput and channel-to-channel precision.  The fiber-optic sampling also allows the ANALECT Diamond MX system to be placed remotely in any general-purpose area.  The system uses the same powerful SpectraRTS™ process software found in the ANALECT Series of on-line and process development FTIR and FT-NIR analyzers.  Our ANALECT Diamond MX’s versatility is demonstrated by its range of applications for raw material QC, on-line and in situ process monitoring and final product inspection in these industries.

SOFTWARE POWERING YOUR ANALYZER

SpectraRTS™ Software – part of our SpectraSuite™ – engineered exclusively for on-line monitoring, allowing use by engineers, maintenance personnel, and chemists.

  • A leading-edge Windows® based software utilized with analyzers for process monitoring, analysis and control.
  • Delivers flexible set-up and control of your system, extensive diagnostics, easy-to-use scripting and robust DCS communications.
  • Easy access tabs display results and system diagnostics.
  • Color-coded status information with click access to detailed information.
  • Full integrated development environment for VB.Net™ compatible scripting language.
  • DCS communications status.
  • Display of statistical data with custom sizing and splitter windows.
  • Control I/O to switch valves and monitor a variety of sample system conditions.
  • Collect spectra and apply quantitative analysis routines.
  • Transmit product properties, instrument QC data, and alarms via versatile communications protocols.
  • Validate and diagnose your system.
  • Implement calibration tools and programming flexibility.
    To Top


    Powerful, Real-Time Benchtop Analyzer for Monitoring Liquids, Solids and Gas Compositions

    ANALECT® Diamond MX

    We Deliver Reliable NIR-UV-VIS &
    FTIR FT-NIR Analyzer Systems

    Got a question?  Not sure what you need?  Just complete the Application Questionnaire.  We’re here to help.

    APPLICATIONS

    Fits a range of applications for raw material QC, on-line and in-situ process monitoring and final product inspection in these industries:

    • Hydrocarbon Processing
    • Polymers
    • Specialty Chemical
    • Materials Processing
    • Pharmaceuticals
